The Neo Classic 3 Column - RD–745 / RD–450 / RD–645 Tweet this item Like this item Expand All
Overview
As Part of the Neo classic range , the Neo–Classic 3 column cast iron radiator is a narrow design suited for areas where space is crucial the design first emerged in 1890 and represented a revival of an earlier classical style. Similar to our Victorian range, the Neo–Classic differs by having a pointed rather than a flat foot on each leg section.
Simple and stylish, its ordered symmetrical design makes it highly efficient in terms of heat output and convection and works perfectly in both period and modern interior schemes.
Customisation
All our radiators are finished using a black primer. Alternately, if you wish, why not let
us paint them from one of the thousands of Ral colours or our specialised finishes. Below are
samples of the many colours that can be used to give you a classic, modern or contemporary look.
Simply ring your nearest dealer or download our brochure for full customisation options.
Technical
DIMENSIONS
LEG SECTION HEIGHT
745mm
SECTION LENGTH
61mm
MIDDLE SECTION HEIGHT
675mm
SECTION DEPTH
120mm
BOTTOM INLET TO FLOOR
115mm
TOP INLET TO FLOOR
700mm
PIPE CENTRES TO SKIRT
60mm
HEAT OUTPUT PER SECTION
Delta ∆T 50˚C
92 Watts / 313 BTUs
Delta ∆T 60˚C
118 Watts / 402 BTUs
WEIGHT
EMPTY WEIGHT PER LEG SECTION
5.44 Kgs
EMPTY WEIGHT PER MIDDLE SECTION
4.8 Kgs
FILLED WEIGHT PER LEG SECTION
6.94 Kgs
FILLED WEIGHT PER MIDDLE SECTION
5.3 Kgs
VOLUME PER LEG SECTION
1.5L
VOLUME PER MIDDLE SECTION
1.5L
*All measurements and sizes are approximate.
DIMENSIONS
LEG SECTION HEIGHT
450mm
SECTION LENGTH
61mm
MIDDLE SECTION HEIGHT
384mm
SECTION DEPTH
120mm
BOTTOM INLET TO FLOOR
115mm
TOP INLET TO FLOOR
405mm
PIPE CENTRES TO SKIRT
60mm
HEAT OUTPUT PER SECTION
Delta ∆T 50˚C
48 Watts / 164BTUs
Delta ∆T 60˚C
60 Watts / 207 BTUs
WEIGHT
EMPTY WEIGHT PER LEG SECTION
3.4 Kgs
EMPTY WEIGHT PER MIDDLE SECTION
3.1 Kgs
FILLED WEIGHT PER LEG SECTION
3.9 Kgs
FILLED WEIGHT PER MIDDLE SECTION
3.6 Kgs
VOLUME PER LEG SECTION
0.5L
VOLUME PER MIDDLE SECTION
0.5L
*All measurements and sizes are approximate.
DIMENSIONS
LEG SECTION HEIGHT
645mm
SECTION LENGTH
61mm
MIDDLE SECTION HEIGHT
578mm
SECTION DEPTH
120mm
BOTTOM INLET TO FLOOR
115mm
TOP INLET TO FLOOR
610mm
PIPE CENTRES TO SKIRT
60mm
HEAT OUTPUT PER SECTION
Delta ∆T 50˚C
73 Watts / 249 BTUs
Delta ∆T 60˚C
92 Watts / 314 BTUs
WEIGHT
EMPTY WEIGHT PER LEG SECTION
4.6 Kgs
EMPTY WEIGHT PER MIDDLE SECTION
4.4 Kgs
FILLED WEIGHT PER LEG SECTION
5.6 Kgs
FILLED WEIGHT PER MIDDLE SECTION
5.4 Kgs
VOLUME PER LEG SECTION
1L
VOLUME PER MIDDLE SECTION
1L
*All measurements and sizes are approximate.
RAL colours
*All RAL swatches below are examples and may not be true to colour shown here, please check with your dealer for a specific RAL colour.
Classic suite
- RAL 1001
- RAL 3002
- RAL 3014
- RAL 4002
- RAL 5013
- RAL 6004
- RAL 7005
- RAL 8008
Modern suite
- RAL 1028
- RAL 2002
- RAL 3005
- RAL 8016
- RAL 4006
- RAL 5005
- RAL 6025
- RAL 7016
Contemporary suite
- RAL 1006
- RAL 1019
- RAL 2009
- RAL 3011
- RAL 4008
- RAL 5002
- RAL 6032
- RAL 7008
